SDT310 Small Type Platinum Thin Film Thermal Sensors
Features
- T.C.R. is in accordance to JIS-DIN IEC standards
- The small package with a real ability of 1kΩ resistance
- Thermal time constant is improved with the small package
- Products meet EU RoHS requirements. EU RoHS regulation is not intended for Pb-glass contained in glass.
Ordering Information CHECK INVENTORY ORDER SAMPLES
Last Updated: 4/1/2025
